Product Introduction

Characteristics

● Built-in LiFePO4 battery cells

● Large capacity, long cycle life

● high safety, environmental protection, IP54


Features

♦ Intelligent communication; Built in fire protection module, 15s fast flame retardant

♦ Support parallel capacity expansion, frame design structure, to meet the demand of large capacity power


Longer Cycle Life

Built in LiFePO4 battery cells

Large capacity

Long cycle life

High safety

Environmental protection

IP54


Intelligent communication

Built in fire protection module

15s fast flame retardant

Support parallel capacity expansion

Frame design structure to meet the demand of large capacity power

Specifications
ModelLF-GS-48v600ah

Rated power

5kw
Peak power10kw
Nominal Voltage51.2v
Nominal Capacity600Ah/30.72kwh
Recommended Charge Voltage54.75V
Discharge Cut-off Voltage37.5V
Standard Discharge Current
<=100A/200A
Standard Charging Current<=100A/200A
Maximum Discharge Current115A
Battery Cycle Life>=6000 Cycle 80%(DOD)
Communication ModeR485/RS232/CAN
Charging Temperature
0~45℃
Operating Temperature-20~60℃
Battery Weight≈355kg
Battery Size605*605*1370mm(adjustable)

Product details

● A wide variety of uses: Equipped with assorted AC and DC outlets, as well as input and output port, our power stations keep all your gears charged, from smartphones, laptops, to CPAP and appliances, like mini coolers, electric grill and coffee maker, etc.

● Smart: Innovative technology, such as fast charging and advanced BMS technology, is introduced for the maximum power performance for different kinds of outdoor activities.

● Certifications: ISO certified plant with product in line with international safety regulation such as CE, RoHS, UN38.3, FCC.

● Easy Installation: Standard design with helpful pulling ear quick stacking.

Certificate








Customer Service

- Professional product consultation and introduction are provided to fully match your needs.

- 24-hour customer service team is ready to provide you with consultation and service.

- All customers will get one-on-one service.

Customize Service

- We offer very flexible customization services like OEM/ODM

- OEM includes color, logo, outer packaging, cable length, etc

- ODM includes function setting, new product development, etc.


After Sale Service

- We offer a one-year quality guarantee period for our products.

- We have a very professional team to solve all the problems encountered in the process of use, they will be at your service 24 hours.


Drop Shipping
  • Express:Door-to-door service, excluding local customs duties and customs clearance fees. Like FEDEX, UPS, DHL...

  • Sea freight:The volume of ocean transportation is large, the cost of ocean transportation is low, and the waterways extend in all directions. However, the speed is slow, the navigation risk is high, and the navigation date is not easy to be accurate.

  • Land freight:(Highway and railway) The transportation speed is fast, the carrying capacity is large, and it is not affected by natural conditions; the disadvantage is that the construction investment is large, it can only be driven on a fixed line, the flexibility is poor, and it needs to be coordinated and connected with other transportation methods, and short-distance transportation high cost.

  • Air freight:Airport-to-airport services, local customs clearance fees and duties, and transportation from the airport to the recipient’s hands all need to be handled by the recipient. Special lines for customs clearance and tax payment services can be provided for some countries. Air freight is carried by airlines, such as CA/EK/AA/EQ and other airlines.




Basic Information
  • Year Established
    --
  • Business Type
    --
  • Country / Region
    --
  • Main Industry
    --
  • Main Products
    --
  • Enterprise Legal Person
    --
  • Total Employees
    --
  • Annual Output Value
    --
  • Export Market
    --
  • Cooperated Customers
    --
BrandiFlowPower
Product Name

iFlowPower Wall Mounted Power Storage Station Powerwall 100A 48V

Nominal Voltage48V / 51.2V
Nominal Capacity100Ah/4.8KWh;200Ah/9.6KWh;100Ah/5.12KWh;200Ah/10.24KWh

Internal Impedance

<=180mΩ
Battery Voltage

48V / 51.2V

Cycle life

5000 Times(80%DOD)
Max Charge Current100A
Max Discharge100A
Standard discharging0.2C constant current discharge to 37.6V
Communication PortR485/R232/CAN
Battery TypeLithium iron phosphate
Size‎575*360*190mm(Adjustable)
Weight‎About 43.5kg
Part NumberFP1850B-2
