  • Product Details
5kw Solar Energy System Benefits Of Off-grid Solar Systems

● Clean, No noise, bad small pollution, Minimize Carbon footprint.

● Save, reduce your electricity costs.

● Convenient, independent of Grid utility, especially for Rural Areas.

● Easy, very easy in installation and operation.

● Smart, can shift between solar and other power resourses freely.

Product List (off grid solar energy system with battery backup)

Solar Inverter - 48V 5000W (1 pcs)

solar Battery - 12V200 Ah - 60 Months Warranty (8 pcs)

Solar Panels - 550Watt (9 pcs)

Ground/Roof Mounting Structure-1 set

PV Cables & MC4-1 set

Data Quick View



Warranty3years
Model NumberFSS-5KW
Output Voltage (V)110/220/220/230/240/380/400V
Load Power5kw
Solar Panel TypeMonocrystalline Silicon, Polycrystalline Silicon
Controller TypeMPPT
Battery Capacity12V 200AH
Inverteroff-Grid Inverter
Mounting TypeGround Mounting, Roof Mounting, Carport Mounting
Application SiteResidential / Commercial
PV Cable4mm²/6mm²/10mm²






Pure sine wave AC output

MPPT solar charge controller to maximize the solar output

WIFI/ GPRS remote monitoring (optional)



Compatible to mains voltage or generator power

Configurable AC/ solar input priority via LCD setting

Parallel operation available












Best user experience




ComponentsQuantity
Inverter 3kw1
Solar Panel 500W9
Gel Battery8
PV Cable ( M )50
MC4 Connecter ( pair )4
Mounting systemGround/Roof
Wifi/GPRS module ( Optional)1




Detailed Specification
Solar panel

● Max. System voltage: 1000V

● 10 years products warranty

● 25 years efficiency Warranty

● Highest conversion efficiency of 19%

● Anti-reflective and anti-soiling surface power loss from dirt and dust

● Excellent mechanical load resistance

● PID Resistant,High salt and ammonia resistance


Charge Controller

● Controlled by TI Digital DSP
● Controlled by high efficient independent MPPT
● Optimal PV output, MPPT rate >99%
● Pure sine wave output
● Automatic synchronization to grid, low harmonics
● Anti-island protected by disturbance detection
● Excellent functions of protection and alarm
● Optional CAN, Ethernet, RS485, Bluetooth ports and remote data collection

Ground/Roof Mountin Structure

● Residential Roof(Pitched Roof)
● Commercial Roof(Flat roof&workshop roof)
● Ground Solar Mounting system
● Vertical wall solar mounting system
● All aluminum structure solar mounting system
● Car parking solar mounting system.

PV Cables

●Maximum Operating Voltage: 800 VRMS
●Temperature Rating: -40°C to 90°C
●Insulation Material: XLPE
●Jacket Material: Sunlight-Resistant PVC
●Min. Bend Radius: 8x Diameter
Battery cables:
●PVC Insulation resists abrasion, fuel, oil, acid, and salt
●Annealed stranded copper conductor
●Copper conductor for maximum conductivity
●Insulation is flame retardant
●Temperature Rating: -50°C to +105°C

Off-grid Inverter

● 3 years warranty under proper application
● MicroProcessor Control
● Adapt to City Grid(or generator)
● Parallel Connective
● Auto Self-Diagnosis
● Touch screen Display and Control
● Robust to heavy load
● Long Service Life
● High system Efficiency

Appliaction
